1. Directly integrated with 10M TCP/IP communication, with excellent transmission performance. 2. Equipped with a large-capacity Flash memory, ensuring that data will not be lost even after a power outage for 10 years. 3. All input interfaces are protected by optocouplers, making the system more stable. 4. The hardware has a built-in Web server, allowing for management and real-time monitoring without the need to install software. 5. Each door has up to 16 groups of door opening times, and different authentication methods can be selected for each group. 6. Multiple door opening authentication methods: card, password, card + password, card or password, double cards, free passage, timed door opening and closing, timed alarm, button operation within a certain time period. 7. Supports remote operation of door opening and closing, activation and deactivation of fire alarms, and alarm triggering. Supports door locking through software or the Web, and anti-tailgating across multiple controllers in a specific area. 8. Supports alarm output for multiple alarm events, such as invalid cards, invalid time periods, door alarms, and door open overtime. 9. All Weigand interfaces are compatible with the 26, 34, and 37 protocols and are protected by optocouplers. At the same time, it supports RS485 card readers or RS485 card readers with screens. 10. Supports setting the validity period of each card individually. All access control devices support mixed installation. When used in conjunction with software, it supports attendance management and real-time online patrol functions. Installing a network camera and using it with a multi-functional electronic map can achieve real-time network monitoring and video capture.
Performance Parameters
1. Card capacity: 30,000 cards 2. Record storage capacity: 50,000 records 3. Alarm capacity: 60,000 alarms 4. Communication method: TCP/IP 5. Communication distance: Software management is not limited by distance 6. Card readers: Wiegand protocol. At the same time, it supports RS485 card readers or RS485 card readers with screens
Door Opening Methods
Card, password, card + password, card or password, double cards, free passage, timed door opening and closing, timed alarm, button operation within a certain time period
Standard Interfaces
1. Card readers: 2 2. Alarm input: 1 3. Alarm output: 1 4. Fire alarm input: 1 5. Fire alarm output: 1 6. Exit button: 1 7. Door magnetic switch input: 1 8. Electric lock output: 1 9. TCP/IP communication: 1 10. RS485 interface: 1
Basic Parameters
1. Mainboard size: 210×125×22mm 2. Mainboard color: Dark blue (standard version) 3. Mainboard weight: Approximately 200 grams 4. Shell size: 214×110×37mm 5. Chassis size: 320×270×72mm; 350×280×72mm (large chassis, can accommodate a storage battery) 6. Chassis color: Black 7. Chassis weight: Approximately 1400 grams (2000 grams for the large chassis) 8. Operating temperature: <60°C 9. Environmental humidity: 10% - 95% R.H 10. Operating voltage: DC 12V 11. Operating current: <80mA 12. Rated power: ≤5W 13. Power outage protection: 10 years
Application Areas
1. Government agencies, scientific research institutions, factories and mines 2. Intelligent buildings, office buildings, office towers 3. Smart residential communities, high-end villas, rental houses 4. Telecommunication machine rooms, banking and financial institutions, vaults 5. Military facilities, prisons 6. Subway transportation, airports, railway stations 7. Gate control systems, parking lots 8. Educational institutions, hospitals, hotels and guesthouses
