1. Fuselage Material
The fuselage is made of aerospace aluminum alloy material, which has the characteristic of being fingerprint-resistant. The surface treatment process involves sandblasting first, followed by anodizing, and finally sealing treatment. With a simple design and smooth lines, the fuselage is easy to clean.
2. Infrared Sensors
The infrared sensors are installed hiddenly beneath the top cover of the pedestrian access gate, greatly enhancing the aesthetic appearance of the device. These sensors can accurately detect the entry and exit status of pedestrians, enabling functions such as automatic opening and closing, anti-collision, anti-pinch, and anti-tailgating.
3. Anti-blocking Protection Mechanism
If the turnstile is blocked by external resistance during the closing process, it will immediately stop operating automatically and reopen. After resetting, the turnstile will automatically return to its initial position and wait for the next passage instruction.
4. Servo Motor System
The product is driven by a servo motor, which can achieve precise control of position, speed, and torque. It has a faster response speed, operates with low noise and generates little heat, and is equipped with a self-checking function. This design can locate faults in a timely manner, reduce the failure rate, and is easy to repair after a malfunction occurs.
5. Mainboard Protection and Configuration Function
The mainboard of the turnstile controller integrates multiple protection functions against overcurrent, overvoltage, and lightning, ensuring more stable operation and a longer service life of the mainboard. It supports the button setting function, allowing various parameters to be freely configured without connecting to a computer.
6. Intelligent Alarm and Self-check Function
The device has functions such as fault self-check, illegal intrusion alarm, and tailgating alarm, making it convenient for maintenance and daily use.
7. Passage Indication Function
It is equipped with a clear passage direction indication function, using ultra-bright LED direction indicator lights. Through intuitive light signals, it clearly shows whether passage is allowed or not.
